Based on the highly successful T-2 advanced trainer, the Mitusbishi F-1 was Japan's first indigenous combat aircraft built after World War II as well as its first supersonic fighter. Sharing a certain resemblance both in shape and function to the Anglo-French Jaguar (including the license-built Adour engines), the F-1 was designed primarily for ground attack missions with a secondary air-to-air capability to replace the elderly F-86 Sabers still in service with the JASDF. The main difference between the F-1 and the T-2 is the faired over rear cockpit which contains additional avionics which allow it to carry a wide range of weaponry including the ASM-1 anti-ship missile although it is capable of carrying other types of air-to-air and air-to-ground ordinance. It is in this maritime strike role where the F-1 continued to serve until being replaced by the more modern F-2.
The F-1 began life as the FS-T2-Kai prototype which took to the air on 3 June 1975. It was a conversion of the T-2 trainer just like the following prototypes which were designated XT-2 until the first production version was rolled out and christened F-1. No major variants have been produced although the aircraft has been given various avionics upgrades, most notably the J/AWG-12 radar which provides compatibility with the ASM-1 air-to-ground missile.
Preceded by:
NoneSucceeded by:
F-2 (2000)Design | F-1 |
Type | Fighter/Attack |
Year | 1977 |
Crew | 1 |
Dimensions | |
Length | 17.86 m |
Height | 4.390 m |
Wing Span | 7.88 m |
Wing Area | n/a |
Weight | |
Empty | 6,358 kg |
Maximum | 13,700 kg |
Wing Loading | 647.1 kg/m² |
Performance | |
Speed | Mach 1.6 |
Ceiling | 15,240 m |
Range | 2,600 km |
Powerplant | |
Engine | 2 x TF40-IHI-801A Ishikawajima-Harima 3,315 kgf |
Thrust/Weight | 0.95 |
Sensors | |
Radar | J/AWG-12 |
Armament | |
Guns | 1 x 20-mm |
Payload | 2,720 kg |
Hardpoints | 7 |
AA Weapons | AAM-1 AIM-9 |
AS Weapons | ASM-1 ASM-2 |
Production | |
Built | 75 |
Total | 77 |
