Air Weapons

Fighter (1937)

Gloster

Gladiator

Gladiator
Gladiator

Obsolescent by the time the war started, the Gloster Gladiator nevertheless was hard pressed for duty due to the RAF's shortage of suitable fighter aircraft. Serving in Europe first (initially in France, later during the Battle of Britain defending the Plymouth Dockyards), it was relegated to second-line duty but used in the front-line in the Mediterranean theater, notably in the defense of Malta and in North Africa where it performed rather admirably. It was over Malta where three navalized Sea Gladiators made a valiant defense against Italian air strikes and were given the nicknames "Faith", "Hope", and "Charity". With an enclosed cockpit and cantilever landing gear, the Gladiator will be remembered as the last British biplane fighter and was also used extensively by over a dozen other nations including combat service by Belgium and Greece as well as China and Finland in the Sino-Japanese and Russo-Finnish wars.

The prototype Gladiator flew as early as September 1934 with the initial production variant being the Mk. I. The main wartime variant was the Mk. II with an uprated engine and optimized for tropical use with desert filters. A naval variant was the Sea Gladiator with catapult points and an arrester hook, initial units were conversions of Mk. I aircraft.

Preceded by:

None

Succeeded by:

None

Datafile

DesignGladiator Mk. IGladiator Mk. II
TypeFighterFighter
Year19371938
Crew11
Dimensions
Length8.36 m8.36 m
Height3.150 m3.150 m
Wing Span9.83 m9.83 m
Wing Arean/an/a
Weight
Empty1,565 kg1,579 kg
Maximum2,155 kg2,182 kg
Wing Loading71.8 kg/m²72.7 kg/m²
Performance
Speed407 km/h414 km/h
Ceiling10,058 m10,211 m
Range689 km708 km
Powerplant
Engine1 x Mercury VIIIA
Bristol
626 kW
1 x Mercury VIIIA
Bristol
626 kW
Thrust/Weight0.490.48
Armament
Guns4 x .303-in
Browning Mk. II
4 x .303-in
Browning Mk. II
Payload--
Production
Built378329
Total747

Gallery
