Ki-84 Hayate 'Frank'

Ki-84 Hayate 'Frank'
Ki-84 Hayate 'Frank'

Designed by T. Koyama, the Nakajima Ki-84 Hayate (Gale) was without question the best Japanese fighter built in large numbers during the war. It had a better rate of climb and could outmaneuver all of the advanced US fighters like the P-51H and P-47N, a fact discovered when one example was captured and tested. In contrast to other Japanese fighters, the Ki-84 did not sacrifice neither pilot protection nor armament to achieve its dogfighting ability but was hampered by poor quality controls as a result of hurried production and a high-maintenance engine; combat units would frequently suffer from accidents, shortages, and poor serviceability the result being that later versions even substituted aluminum for wooden parts. Unfortunately, B-29 raids against the engine plants during the final year of the war prevented larger manufacturing runs which could have made victory far more costly to the Allies had more Ki-84s been deployed in time. Despite these shortcomings, the Ki-84 gave a good account of themselves over China, Taiwan, the Philippines, the Ryukyus, and the Japanese homeland itself.

First flown as a prototype in April 1943, pre-production aircraft began equipping units in China in March 1944. The Production Ki-84-I was first flown against US forces in the Philippines to great success and was available in various different armament configurations which included the Ki-84-Ia, -Ib, and the -Ic which was a dedicated bomber-destroyer with two 20-mm cannon in the nose and two 30-mm cannon in the wings. Later, the Ki-84-II was built with a number of wooden fuselage parts due to the scarcity of aluminum during the final months of the war. Among other designs which never entered production were the all-wooden Ki-106, the Ki-113 which had extensive use of steel in the airframe, and the lightweight Ki-116 equipped with the Ha-32 engine.

Preceded by:

None

Succeeded by:

None

Datafile

DesignKi-84-Ia
NameHayate
Code NameFrank
TypeFighter
Year1944
Crew1
Dimensions
Length9.92 m
Height3.390 m
Wing Span11.24 m
Wing Arean/a
Weight
Empty2,660 kg
Maximum3,890 kg
Wing Loading185.2 kg/m²
Performance
Speed631 km/h
Ceiling10,500 m
Range1,650-2,920 km
Powerplant
Engine1 x Ha-45
Nakajima
1,342 kW
Thrust/Weight0.62
Armament
Guns2 x 20-mm
2 x 12.7-mm
Payload500 kg
Production
Built3,382
Total3,514
