Air Weapons

Night Fighter (1944)

Northrop

P-61 Black Widow

P-61 Black Widow
P-61 Black Widow

The ungainly Northrop P-61 Black Widow has the important distinction of being the only purpose-built Allied night fighter of the war, ironic considering than the lesser need for such aircraft by the USAAF. Large and sinister-looking, it was very effective in that role especially considering how slow the US had been to adopt night fighter technology compared to the British and the Germans. This new twin-boom and twin-engined aircraft was equipped with airborne-radar developed locally from British designs though problems with the radar unit delayed service until 1944. Despite this, P-61s were very effective especially in the Pacific where they were deployed to protect B-29 bases in China and India (P-61s also served in Europe although in lesser numbers). Its menacing name was born out of the prominent all-black finish which characterized many units.

The prototype XP-61 first flew on 21 May 1942 and entered service as the P-61A. Additional refinements led to the P-61B night intruder which was deployed beginning in mid-1944 and was characterized by a lengthened nose and provisions for a considerable bomb load. The final variant was the P-61C with powerful 2,800-hp R-2800-73 engines though other late-war adapations were produced, these included the P-61G unarmed weather reconnaissance aircraft and the F-15A photo-recon platform.

Preceded by:

None

Succeeded by:

F-89 Scorpion (1950)

Datafile

DesignP-61B
NameBlack Widow
TypeNight Fighter
Year1944
Crew3
Dimensions
Length15.11 m
Height4.470 m
Wing Span20.12 m
Wing Arean/a
Weight
Empty9,979 kg
Maximum17,237 kg
Wing Loading279.4 kg/m²
Performance
Speed589 km/h
Ceiling10,089 m
Range2,173 km
Powerplant
Engine2 x R-2800-65
Pratt & Whitney
1,491 kW
Thrust/Weight0.36
Armament
Guns4 x 20-mm
4 x .50-in
M2 Browning
Payload2,903 kg
Production
Built450
Total706

Gallery
