Medium Tank (1940)

London Midland and Scottish

Covenanter

Covenanter Mk. I (British Army)
Covenanter Mk. I

The need for a better protected cruiser tank resulted in the Covenanter, which was a linear descendant from the A13 (Cruisers Mk III and Mk IV) tanks which it strongly resembled. Notable for being the first cruiser tank with a name, the Covenanter was distinguished by having a lower profile as well as armor which reached a maximum thickness of 40-mm. Still, it was designed to use as many components from the A13 series. It's main drawback, however, was that the cooling system was located at the front of the vehicle, while the engine compartment was at the back. This resulted in constant overheating along with other mechanical problems. Some of these were addressed after production was underway but overall, the Covenanter was plagued with difficulties that affected its reliability, particularly in desert conditions where most British tanks were in action at the time. As a result, the Covenanter was never actually used in combat notwithstanding the fact that it was produced in substantial quantities. Most were remained in use as trainers in the UK during 1940-43 although some other non-combat variants did see front-line service.

The Covenanter was inspired by the Soviet T-28 medium tank, which prompted the production of two prototypes, the A14 and A16. However, both proved disappointing during trials on account of noise and low speed and instead, an improved version of the A13 was developed, this becoming the Cruiser Tank Mark V Covenanter (A13 Mk. III). The Covenanter I was the basic variant which was later upgraded into the Covenanter II, III, and IV, with various improvements to the cooling system in order to correct the vehicle's overheating. Those used for close support with a 3-in howitzer were known as the Covenanter CS, while other non-combat variants included the Covenanter Bridgelayer, Covenanter AMRA (Anti-Mine Roller Attachment), Covenanter OP, Covenanter Command, and Covenanter ARV (Armoured Recovery Vehicle).

Preceded by:

Cruiser Mk III/IV (1939)

Succeeded by:

Crusader (1940)

Datafile

DesignCovenanter Mk I
Code NameA13 Mk III
TypeMedium Tank
Year1940
Crew4
Dimensions
Length (w/Gun)19 ft 0 in
Width8 ft 7 in
Height7 ft 4 in
Ground Clearance0 ft 0 in
Track0 ft 0½ in
Track on Ground0 ft 0½ in
Weight
Combat40,320 lbs
Ground Pressure0 psi
SuspensionChristie
Performance
Speed (Off-Road)31 mph (25 mph)
Range (Off-Road)100 mi
AmphibiousNo
Fording3 ft 2 in
Vertical Obstacle2 ft 6 in
Trench7 ft 12 in
Gradient60%
Powerplant
Engine1 x 280-hp
Meadows
Flat-12 DAV
FuelGasoline
Power/Weight15.31 hp/t
Armament
Main1 x 40-mm L/50
QF 2-pounder Mk IX/X

Rifled Gun
↑ 20° / ↓ -15° / ↔ 360°
SecondaryCoaxial:
1 x 7.92-mm
Besa MG
Ammo7.92-mm: 3,750
Armor
TypeSteel
Thickness-
Max Effective-
Production
Built1,771
Total1,771
