Land Weapons

Medium Tank (1944)

Detroit Tank Arsenal / Royal Arsenal Woolwich

Sherman Firefly

Sherman Firefly Mk. Ic (British Army)
Sherman Firefly Mk. Vc

The Sherman Firefly was the result of fitting a Sherman tank hull with a new British-designed turret mounting the powerful 17-pounder gun. When the US Sherman tank became equipping British armored units in late 1942 it was the most powerful tank in its arsenal, and the only one capable of taking on contemporary Panzer IIIs and IVs. Only until 1944 did the British field tanks of comparable firepower (the Cromwell and upgunned Churchill) by which time these too had fallen behind against the latest German tanks, notably the Panther which became one the most widely encountered after the Normandy landings. The use of the 17-pounder on the Sherman finally allowed the Allies to have a tank that was capable of defeating German tanks at a distance and although it still retained the Sherman hull's deficiencies (mainly its weak armor), it became one of the most valuable assets during the campaign in Northwest Europe. A shortage of guns prevented the Firefly to be fielded in large numbers after D-Day, just one per troop, but by 1945 was found in larger numbers. Despite being offered to the US, it was rejected due to preference for its own 90-mm gun. As such, the only foreign operators were British Commonwealth forces along with Czechoslovakian and Polish forces that fought alongside the the British. Some were used in Italy as well.

Merging the Sherman hull and the 17-pounder gun was initially suggested in January 1943 as a preventive measure in the event that the Challenger (A30) were to prove a failure. A pilot conversion was ready by November 1943 and production began in February 1944 with initial units ready by D-Day. Fireflies were designated with a C suffix to their standard Sherman designations, these included the Sherman Mk. Ic (Firefly) based on the M4, the Mk. IVc (M4A3), and the Mk. Vc (M4A4), the latter which was the most widely produced conversion.

Preceded by:

None

Related:

M4 Sherman (1942)

Succeeded by:

None

Datafile

DesignSherman Mk Vc
NameFirefly
TypeMedium Tank
Year1944
Crew5
Dimensions
Length (w/Gun)19 ft 10 in (25 ft 9 in)
Width8 ft 7 in
Height8 ft 12 in
Ground Clearance0 ft 0 in
Track0 ft 0½ in
Track on Ground0 ft 0½ in
Weight
Combat69,700 lbs
Ground Pressure13.20 psi
SuspensionVertical volute
Performance
Speed (Off-Road)25 mph
Range (Off-Road)100 mi
AmphibiousYes (20 mph)
Fording3 ft 6 in
Vertical Obstacle2 ft 12 in
Trench8 ft 12 in
Gradient60%
Powerplant
Engine1 x 370-hp
Chrysler
A57
FuelGasoline
Power/Weight11.70 hp/t
Armament
Main1 x 76.2-mm L/55
QF 17-pounder Mk IV

Rifled Gun
↑ 25° / ↓ -10° / ↔ 360°
SecondaryCoaxial:
1 x 7.62-mm
M1919A4 .30 cal
Anti-Aircraft:
1 x 12.70-mm
M2HB .50 cal
Ammo7.62-mm: 5,000
Armor
TypeSteel
Thickness19 - 76 mm
Max Effective88 - 91 mm RHAe
Hull Upper Front50.8 mm / 56°
Hull Lower Front50.8 mm / 45°
Hull Upper Sides38.1 mm
Hull Lower Sides38.1 mm
Hull Lower Rear38.1 mm
Hull Top19.05 mm / 83°
Hull Bottom25.4 mm
Turret Mantlet76.2 mm
Turret Front76.2 mm / 30°
Turret Sides50.8 mm / 5°
Turret Rear50.8 mm
Turret Top25.4 mm
Production
Built7,499
Total2,139
