Land Weapons

Main Battle Tank (1992)

GIAT Industries

Leclerc

Leclerc
Leclerc

The Leclerc, initially begun as a Franco-German collaboration, was therefore the answer to the AMX-30's shortcomings in terms of weak protection, providing the French Army with its first third generation tank. Despite having a traditional tank layout, the Leclerc is unique in featuring an auto-loader for its 120-mm smoothbore gun, something generally shunned by NATO tanks due to its slower rate of fire compared with manually-loaded guns. Nevertheless, the gun's long muzzle gives its depleted-uranium or tungsten APFSDS rounds extra velocity and it is able to use US and German ammunition for added commonality. Passive protection is provided by welded steel and modular composite armor, but semi-reactive explosive materials are also included in later upgrades. Like most modern tanks, the Leclerc is also fitted with NBC protection, deep-fording equipment and advanced optical and ballistic equipment. The Leclerc has yet to see active combat, although it has been used in various peacekeeping operations including Kosovo (KFOR) and Lebanon (UNIFIL). The only export customer has been the United Arab Emirates whose units feature numerous enhancements for use in tropical climates.

Following the breakdown of collaboration with West Germany in December 1982, the Leclerc prototype was seen in 1989. It was also referred during development as the AMX-56 although this was not adopted officially in production versions. The Leclerc, entered service in 1992, just missing out on the Gulf War. It has been produced in three series, of which Series 1 (or Block I), which accounts for the first five production tranches, was the basic initial variant for use in Central Europe. This was followed by the Series 2 (Block II) consisting of tranches six to eight with a climate-control system, enhanced software and add-on armor. Lastly, the Series XXI (or Block II+) from tranche nine and above has more advanced equipment and the ICONE battle management system. The DNG (Depanneur Novelle Generation) is an armored recovery vehicle based on the Leclerc chassis.

Preceded by:

AMX-30 (1966)

Succeeded by:

None

Datafile

DesignLeclerc S.2
TypeMain Battle Tank
Year1992
Crew3
Dimensions
Length (w/Gun)22 ft 7 in (32 ft 5 in)
Width12 ft 2½ in
Height8 ft 4 in
Ground Clearance0 ft 0 in
Track0 ft 0½ in
Track on Ground0 ft 0½ in
Weight
Combat124,561 lbs
Ground Pressure12.80 psi
SuspensionHydropneumatic
Performance
Speed (Off-Road)45 mph (31 mph)
Range (Off-Road)280-342 mi
AmphibiousNo
Fording3 ft 3 in (13 ft 1 in)
Vertical Obstacle4 ft 1 in
Trench10 ft 10 in
Gradient60%
Powerplant
Engine1 x 1,500-hp
SACM
V8X-1500
FuelDiesel
Power/Weight26.55 hp/t
Armament
Main
SecondaryCoaxial:
1 x 12.70-mm
M2HB .50 cal
Anti-Aircraft:
1 x 7.62-mm
AAN F1
Ammo7.62-mm: 3,000
Armor
TypeComposite/Modular
Thickness600 - 700 mm
Max Effective600 - 700 mm RHAe
Hull Upper Front600 mm
Turret Front700 mm
Production
Built406
Total862
