Medium Tank (1936)

SOMUA

S35

S35
S35

The SOMUA S35 was the standard medium tank of the French Army at the beginning of World War II and is considered by some to have been possibly the best in the world when it first entered service in the late 1930s. The S35 had a good combination of firepower, armor protection and mobility but also suffered from various design flaws. Armament was composed of a 47-mm SA 35 gun which was adequate for its day, while armor protection reached 56mm maximum in the turret (the same used in the Char B1 heavy tank) and 41mm in the hull, both of which were moderately sloped. Suspension was of a semi-elliptical leaf springs, with nine roadwheels paired on four bogies (the ninth had its own spring). Unfortunately, like all French tanks, the turret was operated by a single crewman which limited its effectiveness. The three-piece bolted cast hull was also vulnerable to a shot against the joints. Despite this, the S-35 was capable of holding its own against the German medium panzers in 1940 but was hampered by the turret as well as the lack of radios in many units (despite having provision for it). Additionally, French tactics during the critical first days of the invasion did not allow it to be implemented in the most efficient way. Surviving examples after the French defeat were taken over by the Germans where they used on various fronts and were still in service as late as 1945.

An early requirment for the AMC Automitrailleuse de Combat was issued in the early 1930s and a prototype was accepted for service with the cavalry as the AC3 and later with the Army as the S35. An improved S40 was planned for production in 1940 with a more powerful engine and improved suspension but this project was cut short by the defeat. Another prototype was the SAu 40 self-propelled gun. In German service the S-35 was known as the PzKpfw 35C 739(f) and were frequently modified for other roles including training vehicles, internal security and command vehicles.

Preceded by:

None

Succeeded by:

Char D2 (1940)

Datafile

DesignS35
TypeMedium Tank
Year1936
Crew3
Dimensions
Length (w/Gun)17 ft 8 in
Width6 ft 11 in
Height8 ft 7½ in
Ground Clearance0 ft 0 in
Track0 ft 0½ in
Track on Ground0 ft 0½ in
Weight
Combat42,990 lbs
Ground Pressure13.09 psi
SuspensionLeaf springs
Performance
Speed (Off-Road)23 mph
Range (Off-Road)160 mi
AmphibiousNo
Fording3 ft 3 in
Vertical Obstacle2 ft 6 in
Trench7 ft 12 in
Gradient60%
Powerplant
Engine1 x 190-hp
SOMUA
FuelGasoline
Power/Weight9.74 hp/t
Armament
Main1 x 47-mm L/32
47mm SA 35

Rifled Gun
↑ 18° / ↓ -18° / ↔ 360°
SecondaryCoaxial:
1 x 7.50-mm
7.5mm MAC 31
Ammo7.5-mm: 3,750
Armor
TypeSteel
Thickness20 - 56 mm
Max Effective39 - 56 mm RHAe
Hull Upper Front36 mm / 22°
Hull Lower Front36 mm / Round
Hull Upper Sides35 mm / 22°
Hull Lower Sides35 mm
Hull Lower Rear35 mm
Hull Top20 mm / 82°
Hull Bottom20 mm
Turret Mantlet56 mm / Round
Turret Front56 mm
Turret Sides46 mm / 22.5°
Turret Rear46 mm / 22.5°
Turret Top30 mm / 72.5°
Production
Built418
Total418
