Main Battle Tank (1947)

Kharkiv Morozov

T-54 / T-55

T-55
T-54B
T-55
T-55AM

The T-54 and T-55 series of main battle tanks have the distinction of being the most widely produced tanks in history, exceeding even the production runs of the wartime T-34 and M4 Sherman when Soviet as well as license-production is included. The T-54/55 were revolutionary designs for their day, being arguably the first true main battle tanks developed in the Soviet Union given their combination of armament, armor and speed (although Soviet authorities designated them as medium tanks likely because heavies like the IS-3 and T-10 were still in service). Its layout also became standard for all Soviet tanks since then, characterized by the rounded (nearly hemispherical in the T-55) cast turret that provided excellent ballistic protection for its time despite its cramped nature compared to taller but roomier Western tanks. The relatively small profile is also an advantage although this limits the gun's depression, a problem also seen in its successors. Armor was adequate for its time, particularly up front, but weaker side and rear armor made it vulnerable in more closed environments. The T-54/T-55 series were based on the 100-mm D-10T rifled gun, which had been previously seen in an earlier incarnation in the wartime SU-100 assault gun. This was competitive with contemporary NATO guns, at least until the introduction of the British L7 in the late 1950s. This disadvantage was partly compensated by the addition of 9M117 (AT-10) ATGMs in later versions although hull limitations meant the T-55 could not be upgraded with more powerful guns. Though absent on the T-54, the T-55 became the first Soviet tank with NBC protection to provide survivability in a nuclear environment. It was also able to lay a smoke screen by injecting diesel fuel into the exhaust, a feature that remained present in all subsequent diesel-fueled Soviet tanks. The T-54 entered Soviet service shortly after World War II with the T-55 following suit in the late 1950s, becoming the mainstay of Soviet tank forces throughout the first half of the Cold War and largely rendering heavy tanks obsolete. More advanced fire control systems including laser designators as well as appliqué armor was also added to keep the large inventories of these vehicles competitive into the 1980s, though it has been relegated to storage since. License production of the T-54 took place in China (as the Type 59), and of the T-55 in Poland and Czechoslovakia. Up to 50 countries eventually adopted it for service, and it saw action in the Indo-Pakistani and Arab-Israeli wars (where it proved to be roughly equal to the US M48), the Vietnam War, the Iran-Iraq War, as well as the Gulf War, by which time they were thoroughly outclassed by modern Western designs and as a consequence suffered heavy losses. More notoriously, the T-54 and T-55 were used in large numbers to repress anti-Soviet uprisings in Hungary (1956) and Czechoslovakia (1968), with a number of them destroyed by partisans. Despite its obsolescence, the T-55 remains in service with dozens of countries worldwide thanks to its low cost and good reliability, and availability of upgrades (including Western equipment) in order to remain viable in the modern battlefield.

The prototype of a successor to the wartime T-44 was completed in 1946 (as Ob'yekt 137), with production commencing the following year. The initial T-54 Model 1946 featured a more traditional turret, reminiscent of the T-34 and T-44, but limited production gave way to improved versions that corrected some of the design's early problems. The turret gradually evolved into its familiar shape as the Model 1949 (the first true production version), Model 1951, and Model 1953 were developed. A major upgrade in the mid-1950s resulted in the T-54A with the vertically-stabilized D-10TG gun with power-operated elevation and a snorkel for amphibious operations, and the T-54B with, with a two-axis stabilized D-10T2S as well as night-fighting equipment. By the late 1950s, production switched to the improved T-55 (Ob'yekt 155). This introduced NBC protection as well as a rotating turret floor, while increasing fuel capacity as well as ammunition load. The NBC system was further refined in the T-55A which also featured different secondary armament configurations. Converted T-54s to T-55 standard were known as the T-54M. A further modernization program took place in the 1980s and resulted in the T-55M with a new fire control system, engine, suspension and equipment as well as the ability to carry AT-10 anti-tank missiles. Some also received Kontakt-1 ERA and were designated T-55MV, while the T-55BV incorporates the more advanced Kontakt-5. Other modern versions include the T-55AM with added passive armor protection, and the T-55AD with the Drozd anti-tank missile system. There are further upgraded available for export, and which incorporate some of the features of more modern tanks like the T-80. Command versions (of which there were numerous sub-variants) were known as the T-54K and T-55K series. Other variants include the OT-54 and TO-55 flame-thrower tanks, the BTS series of armored recovery vehicles, the SPK-12G heavy crane, the MTU-1 and MTU-20 bridgelayers, and the IMR combat engineer vehicle. An assault gun known as the SU-122 was fitted with a 122-mm gun but most were later converted into ARVs, additionally the BTR-T was a heavy APC based on the T-55's chassis. Foreign variants are too numerous to list but most operators eventually incorporated local improvements and modifications (the Chinese Type 59 is listed separately). Captured Israeli tanks were known as the Tiran series, some with domestically-produced guns.

Preceded by:

T-34 (1940)

Related:

BTR-T (1997)

Succeeded by:

T-62 (1961)

Datafile

DesignT-54 (M1953)T-54AT-55AT-55AM
TypeMain Battle TankMain Battle TankMain Battle TankMain Battle Tank
Year1953195519631983
Crew4444
Dimensions
Length (w/Gun)6.04 m (9 m)6.04 m (9 m)6.20 m (9 m)6.20 m (9 m)
Width3.270 m3.270 m3.270 m3.270 m
Height2.400 m2.400 m2.400 m2.400 m
Ground Clearance0.425 m0.450 m0.425 m0.425 m
Track2.640 m2.640 m2.640 m2.640 m
Track Width580 mm580 mm580 mm580 mm
Track on Ground3.840 m3.840 m3.840 m3.840 m
Weight
Combat36,000 kg36,000 kg36,000 kg40,500 kg
Ground Pressure0.81 kg/cm²0.81 kg/cm²0.81 kg/cm²0.89 kg/cm²
SuspensionTorsion barTorsion barTorsion barTorsion bar
Performance
Speed (Off-Road)50 km/h (35 km/h)50 km/h (35 km/h)50 km/h (35 km/h)50 km/h (35 km/h)
Range (Off-Road)510 km510-720 km460-650 km385-545 km
AmphibiousNoNoNoNo
Fording1.40 m (5 m)1.40 m (5 m)1.40 m (5 m)1.40 m (5 m)
Vertical Obstacle0.80 m0.80 m0.80 m0.80 m
Trench2.70 m2.70 m2.70 m2.70 m
Gradient60%60%60%60%
Powerplant
Engine1 x 520-hp
V-54
1 x 520-hp
V-54G
1 x 580-hp
V-55
1 x 620-hp
V-55U
FuelDiesel: 812 LDiesel: 817 LDiesel: 965 LDiesel: 965 L
Power/Weight14.44 hp/t14.44 hp/t16.11 hp/t15.31 hp/t
Armament
Main1 x 100-mm L/53.5
D-10T

Rifled Gun
↑ 17° / ↓ -5° / ↔ 360°
1 x 100-mm L/53.5
D-10TG

Rifled Gun
↑ 17° / ↓ -5° / ↔ 360°
1 x 100-mm L/53.5
D-10T2S

Rifled Gun
↑ 18° / ↓ -5° / ↔ 360°
1 x 100-mm L/53.5
D-10T2S

Rifled Gun
↑ 18° / ↓ -5° / ↔ 360°
SecondaryCoaxial:
1 x 7.62-mm
SGMT
Bow:
1 x 7.62-mm
SGMT
Anti-Aircraft:
1 x 12.70-mm
DShKM
Coaxial:
1 x 7.62-mm
SGMT
Bow:
1 x 7.62-mm
SGMT
Anti-Aircraft:
1 x 12.70-mm
DShKM
Coaxial:
1 x 7.62-mm
SGMT
Anti-Aircraft:
1 x 12.70-mm
DShKM
Coaxial:
1 x 7.62-mm
SGMT
Anti-Aircraft:
1 x 12.70-mm
DShKM
Ammo7.62-mm: 3,000
7.62-mm: 3,000
7.62-mm: 3,500
7.62-mm: 1,500
Armor
TypeSteelSteelSteelSteel/Appliqué
Thickness20 - 203 mm20 - 203 mm20 - 203 mm20 - 203 mm
Max Effective183 - 203 mm RHAe183 - 203 mm RHAe183 - 203 mm RHAe183 - 203 mm RHAe
Hull Upper Front97 mm / 58°97 mm / 58°97 mm / 58°97 mm / 58°
Hull Lower Front99 mm / 55°99 mm / 55°99 mm / 55°99 mm / 55°
Hull Upper Sides79 mm79 mm79 mm79 mm
Hull Lower Sides20 mm20 mm20 mm20 mm
Hull Upper Rear46 mm46 mm46 mm46 mm
Hull Lower Rear46 mm46 mm46 mm46 mm
Hull Top33 mm33 mm33 mm33 mm
Hull Bottom20 mm20 mm20 mm20 mm
Turret Mantlet203 mm / Round203 mm / Round203 mm / Round203 mm / Round
Turret Front203 mm / Round203 mm / Round203 mm / Round203 mm / Round
Turret Sides150 mm / Round150 mm / Round150 mm / Round150 mm / Round
Turret Rear64 mm / Round64 mm / Round64 mm / Round64 mm / Round
Turret Top39 mm / 79°39 mm / 79°39 mm / 79°39 mm / 79°
Production
Built10,2454,6028,462n/a
Total65,000
