The Malyshev Plant (ZiM) based in Kharkiv was one of the most important tank factories of the USSR and was responsible for producing Soviet tanks like the T-64 and T-80. Following the independence of Ukraine in 1991, it developed an indigenous version of the T-80 known as the T-84. The T-84's hull is based on that of the T-80UD variant and retains is basic layout, with the main difference being the substitution of the original gas turbine engine for a more fuel-efficient diesel 6TD engine which also gives it one of the best power-to-weight ratios in a main battle tank. The original cast turret has also been replaced by a new all-welded design composed of steel and composite armor. Reactive armor is also typically installed in both the hull and turret. Armament is initially identical to that of the T-80, based on a 125-mm KBA-3 smoothbore gun (a locally-built version of the 2A45M-1) fed by an automatic loader. It can fire the same ammunition as that of a T-80 and T-72 as well as a locally-designed Combat ATGM. Newer variants are quipped with a NATO-standard 120-mm smoothbore. Defensive armament consists of coaxial 7.62-mm PKT and turret-mounted 12.7-mm NSVT machine guns, and an active protection system is also equipped. The T-84 became the first tank to be received to the Ukrainian army after independence but only a handful of vehicles have been delivered. The main user has been Thailand which so far is the only export client, although Pakistan has planned to upgrade its T-80UDs to T-84 standard.
Development a new tank based on the T-80UD began in 1993 and resulted in the T-84. Equipment upgrades along with Kontakt-5 ERA resulted in the T-84U which was further developed into the T-84-120 Oplot which features a NATO-standard 120-mm gun, Duplet ERA, Zaslin APS, and a new PNK-6 panoramic tank sight. An IFV, ARV and SPAAG based on the T-84 have also been proposed but have not been developed.
Design | T-84 | T-84-120 |
Name | - | Oplot |
Type | Main Battle Tank | Main Battle Tank |
Year | 2001 | 2014 |
Crew | 3 | 3 |
Dimensions | ||
Length (w/Gun) | 7.09 m (9.72 m) | 7.09 m (9.72 m) |
Width | 3.775 m | 3.775 m |
Height | 2.740 m | 2.740 m |
Ground Clearance | 0.515 m | 0.515 m |
Track | 2.800 m | 2.800 m |
Track Width | 580 mm | 580 mm |
Track on Ground | 4.290 m | 4.290 m |
Weight | ||
Combat | 46,000 kg | 48,000 kg |
Ground Pressure | 0 kg/cm² | 0 kg/cm² |
Suspension | Torsion bar | Torsion bar |
Performance | ||
Speed (Off-Road) | 65 km/h | 70 km/h |
Range (Off-Road) | 540 km (350 km) | 500 km (400 km) |
Amphibious | No | No |
Fording | 1.80 m (5 m) | 1.80 m (5 m) |
Vertical Obstacle | 1 m | 1 m |
Trench | 2.85 m | 2.85 m |
Gradient | 63% | 63% |
Side Slope | 36% | 36% |
Powerplant | ||
Engine | 1 x 1,200-hp KMDB 6TD-2 | 1 x 1,200-hp KMDB 6TD-2D |
Fuel | Diesel: 1,300 L | Diesel: 1,300 L |
Power/Weight | 26.09 hp/t | 25.00 hp/t |
Armament | ||
Main | 1 x 125-mm L/48KBA-3Smoothbore Gun↑ 13.5° / ↓ -5.67° / ↔ 360° | 1 x 120-mm(Unknown)Smoothbore Gun↑ 13.5° / ↓ -5.67° / ↔ 360° |
Secondary | Coaxial:1 x 7.62-mmPKTAnti-Aircraft: 1 x 12.70-mmNSVT | Coaxial:1 x 7.62-mmPKTAnti-Aircraft: 1 x 12.70-mmNSVT |
Ammo | - | 7.62-mm: 1,250 |
Armor | ||
Type | Composite/ERA | Composite/ERA |
Thickness | - | - |
Max Effective | - | - |
Production | ||
Built | 5 | 49 |
Total | 53 |
