Light Tank (1940)

Vickers-Armstrong

Tetrarch

Tetrarch Mk. I (British Army)

The Tetrarch (A17) was the last of a long series of Vickers light tanks to be used in combat, albeit in much smaller numbers that was originally intended. It's design was directly based on that of its predecessor, the Light Tank Mk VI, but with the added punch of a 2-pounder gun (the standard gun for British medium tanks at the time) as well as numerous mechanical improvements. This included a variation of the Christie suspension as well as a removable track for better road performance. Otherwise, however, performance was limited by the weak gun, intentionally weak protection, and poor visibility for the commander, who also acted as a loader. Production the Tetrarch was delayed by shifting priorities (caused by the poor performance of light tanks during the Spanish Civil War), as well as the fact that the factory was bombed during the Blitz. As a result only a few were built, and saw only brief combat in Madagascar and North Africa where its poor cooling became a liability. It was eventually determined to use it as an air transportable tank and saw action during the Normandy airborne landings as well as the crossing of the Rhine in 1945 where they were carried by a purpose-built glider, the Hamilcar. They nevertheless remained in service until gliders were retired in 1950 and 20 were sent to the USSR during the war as part of Lend-Lease.

The A17 was initially offered in 1938 and known as the Purdah, with an order placed late that year as the Light Tank Mark VII Tetrarch. Aside from the basic tank version, the Tetrarch I CS was converted with a 3-in howitzer, while the Tetrarch DD featured a propeller drive and a flotation screen but not used in combat. A proposed successor was known as the Light Tank Mk VIII Harry Hopkins (A25). This had improved armor and a redesigned hull shape but despite plans for mass production, only around a hundred were built and were not used in combat. Some were completed late in the war as Aleco Dozers.

Preceded by:

Light Tank Mk VI (1937)

Succeeded by:

None

Datafile

DesignTetrarch Mk I
NameTetrarch
Code NameA17
TypeLight Tank
Year1940
Crew2
Dimensions
Length (w/Gun)13 ft 6 in
Width7 ft 7 in
Height6 ft 11 in
Ground Clearance0 ft 0 in
Track0 ft 0½ in
Track on Ground0 ft 0½ in
Weight
Combat16,800 lbs
Ground Pressure0 psi
SuspensionIndependent
Performance
Speed (Off-Road)40 mph (28 mph)
Range (Off-Road)140 mi
AmphibiousNo
Fording3 ft 12 in
Vertical Obstacle2 ft 8 in
Trench5 ft 12 in
Gradient60%
Powerplant
Engine1 x 165-hp
Meadows
MAT
FuelGasoline
Power/Weight21.65 hp/t
Armament
Main1 x 40-mm L/50
QF 2-pounder Mk IX/X

Rifled Gun
↑ 25° / ↓ -12° / ↔ 360°
SecondaryCoaxial:
1 x 7.92-mm
Besa MG
Ammo7.92-mm: 2,025
Armor
TypeSteel
Thickness4 - 14 mm
Max Effective4 - 14 mm RHAe
Production
Built171
Total177
