| Class | Courageous |
| Type | Fleet Carrier |
| Year | 1928 |
| Crew | 1216 |
| Dimensions | |
| Length | 224.0 m (pp) 239.8 m |
| Beam | 27.6 m |
| Draught | 8.5 m - 8.5 m |
| Displacement | |
| Empty | 22,500 t |
| Loaded | 27,400-27,560 t |
| Performance | |
| Speed | 56 km/h |
| Range | 13,853 km @ 19 km/h |
| Machinery | |
| Shafts | 4 |
| Turbines | 4 x Geared steam 72,500 hp Parsons |
| Boilers | 18 x Yarrow |
| Fuel | Oil: 3,450-3,685 t |
| Armament | |
| Main | 16 x 119-mm/43 (16 x 1) QF 4.7"/43 Mk. VIII -5° / +50° |
| Anti-Aircraft | 4 x 40-mm (4 x 1) QF 2-pdr Mk. II |
| Armor | |
| Belt | 76 mm |
| Aircraft | |
| Aircraft | 48 |
| Production | |
| Built | 1 |
| Total | 2 |
| Ship | Code | Builder | Laid | Launch | Comm | Decomm | Fate | ||
|
Courageous † | 50 | Armstrong | 28/03/1915 | 05/02/1916 | 05/05/1928 | 17/09/1939 | † | Loss by submarine |
|
Glorious † | 77 | Harland & Wolff | 01/05/1915 | 20/04/1916 | 10/03/1930 | 08/06/1940 | † | Loss by surface ship |
