| Class | Yorktown |
| Type | Fleet Carrier |
| Year | 1937 |
| Crew | 2175 |
| Dimensions | |
| Length | 234.7 m (pp) 246.6 m |
| Beam | 25.3 m - 33.7 m (d) |
| Draught | 7.9 m |
| Displacement | |
| Empty | 19,875 t |
| Loaded | 25,484 t |
| Performance | |
| Speed | 60 km/h |
| Range | 22,224 km @ 28 km/h |
| Machinery | |
| Shafts | 4 |
| Turbines | 4 x Geared steam 120,000 hp General Electric |
| Boilers | 9 x Babcock & Wilcox |
| Fuel | Oil: 2,754-4,360 t |
| Armament | |
| Main | 8 x 127-mm/38 (8 x 1) 5"/38 Mk. 12 -10° / +35° |
| Anti-Aircraft | |
| Armor | |
| Belt | 64 - 102 mm |
| Bulkhead | 102 mm |
| Deck | 38 - 76 mm |
| Conning tower | 51 - 102 mm |
| Aircraft | |
| Aircraft | 96 |
| Production | |
| Built | 3 |
| Total | 3 |
| Ship | Code | Builder | Laid | Launch | Comm | Decomm | Fate | ||
|
Yorktown † | CV-5 | Newport News SB | 21/05/1934 | 04/04/1936 | 30/09/1937 | 04/06/1942 | † | Loss by submarine |
|
Enterprise | CV-6 | Newport News SB | 16/07/1934 | 03/10/1936 | 12/05/1938 | 17/02/1947 | Sold/Scrapped | |
|
Hornet † | CV-8 | Newport News SB | 25/09/1939 | 14/12/1940 | 25/10/1941 | 26/10/1942 | † | Loss by aircraft |
