Sea Weapons

Attack Submarine, Nuclear (1983)

Trafalgar class

HMS Tireless (S88)

The Trafalgar-class are the successors to the Swiftsure-class and remain the most widely used nuclear attack submarines in the Royal Navy. They were designed as refinements of the Swiftsure boats albiet with noticeably higher displacement, and feature the same coating of anechoic tiles to reduce reflections from active sonar. They are also equipped with a pump-jet propulsion system for additional noise reduction. The Trafalgar-class is designed with five torpedo tubes which can carry a combination of weapons including Spearfish and Tigerfish wire-guided torpedoes as well as Harpoon anti-ship missiles and US Tomahawk cruise missiles. This gives them significant land-attack capability which they have used to good effect in various conflicts. Sensors include a hull-mounted Type 2020 active/passive sonar which was later replaced by the more advanced Type 2074 or Type 2076. Combined with pump jets and anechoic tiles, the Trafalgars are among the quietest nuclear submarines in the world. Various ships in the class have seen extensive action in Iraq, Afghanistan, and Libya primarily for launching Tomahawks. They are expected to be replaced by the Astute-class on a one-to-one basis; the first two ships have therefore already been decommissioned.

Three of the ships have been used to fire Tomahawks in combat: HMS Trafalgar (Afghanistan), HMS Turbulent (Iraq), and HMS Triumph (Afghanistan and Libya). Either HMS Tireless or HMS Turbulent were deployed to the South Atlantic in early 2012 due to increased tension with Argentina over the Falklands. HMS Tireless was also used in the search for missing airliner MH370 in the Indian Ocean.

Preceded by:

Swiftsure (1973)

Succeeded by:

Astute (2010)

Datafile

ClassTrafalgar
TypeBallistic Missile Submarine, Nuclear
Year1983
Crew130
Dimensions
Length85.4 m
Beam9.8 m
Draught9.5 m
Displacement
Empty4,700 t
Surfaced
Submerged
Performance
Speed59 km/h
RangeUnlimited
Depth300 m
Machinery
Shafts1
Turbines2 x Steam turbine
15,000 hp
GEC 2
2800

Boilers1 x Rolls-Royce
PWR 1
FuelNuclear
Armament
Torpedo tubes5 x 533-mm (Bow)
AA WeaponsSpearfish
Tigerfish
UGM-84
UGM-84E
UGM-109
Armor
ArmorNone
Sensors
RadarType 1007
SonarType 2007AC/2072
Type 2019/2082
Type 2020/2074
Type 2046
Type 2077
Production
Built7
Total7

Registry

Ship Code Builder Laid Launch Comm Decomm Fate
Trafalgar S107 VSEL25/04/197901/07/198127/05/198304/12/2009Inactive
Turbulent S87 VSEL08/05/198001/12/198228/04/198414/07/2012Inactive
Tireless S88 VSEL06/06/198117/03/198405/10/198519/06/2014Inactive
Torbay S90 VSEL03/12/198208/03/198507/02/198714/07/2017Inactive
Trenchant S91 VSEL28/10/198503/11/198614/01/198920/05/2022Inactive
Talent S92 VSEL13/05/198615/04/198812/05/199020/05/2022Inactive
Triumph S93 VSEL02/02/198716/02/199112/10/1991-Active

Gallery
